Precision Injection available with a next-generation new controller, guarantees high-performance, precision control and safety.
Characteristic
- ·Touch screen controller
- ·12.1" TFT True Color LCD
- ·User interface enhancement (touch and keyboard at the same time)
- ·USB memory-molding memory, screen capture, program download available
- ·User level by password
- ·Injection speed graph and production data comparison graph display
- ·200 internal mold data
- ·500 external storage of mold data (optional)
- ·Providing experienced communication protocol for integrated management of Injection
Operation Monitor
- Operation progress display temperature, pressure display operation
- Temperature status display machine operation screen display
- Display of various location status
- Injection 5 stages, holding pressure 3 stages
- High-speed Injection function using accumulator
- Control cushion by selecting the Injection distance/time/time + distance
Injection
- Operation progress display temperature, pressure display operation
- Temperature status display machine operation screen display
- Display of various location status
- Injection 5 stages, holding pressure 3 stages
- High-speed Injection function using accumulator
- Control cushion by selecting the Injection distance/time/time + distance
Metering
- 5-step weighing control and back pressure control
- Anti-pollution selectable before/after weighing automatic purging possible
- Manual back pressure function
Temperature
Auto PID Temperature Control
Target Temperature Realiztion
- Operation progress display temperature, pressure display operation
- Temperature status display machine operation screen display
- Display of various location status
- Injection 5 stages, holding pressure 3 stages
- Control cushion by selecting the Injection distance/time/time + distance
- High-speed Injection possible using accumulator
Ejector
- Controlling Ejector forward/reverse 2-stage
- Controlling Ejector operation basic / continuous / standby selection
- Air blow function
Alam
- Alarm history storage function
- Save alarm time and release time
- Save up to 200 latest alarm history
SPC
- Saving Injection data related to quality every time one process is completed
- Save up to 200 SPC data
- SPC data saving function to the last 200 USB memory
◆ Features
- · Vertical clamping, horizontal injection type
- · High sensibility mold protection
- · Applicable for a wide variety of mold types. (including general horizontal type molds)
- · Proportional control by clamp pressure sensor
- · Proportional back pressure control.
- · 10.4″Color TFT LCD provided.
- · Forward slide type. (VTU-HCSL)
◆ Die Plate Size
| VTU-100HC | VTU-150HC | VTU-200HC | VTU-250HC | VTU-300HC | |
|---|---|---|---|---|---|
| A | 785 | 970 | 1080 | 1200 | 1350 |
| B | 620 | 770 | 870 | 970 | 1080 |
| C | 565 | 695 | 790 | 880 | 980 |
| D | 405 | 495 | 560 | 630 | 700 |
| Item | Screw Type | Screw Diameter | Injection Pressure | Injection Capacity | Injection Weight (PS) | Injection Rate | Injection Stroke | Screw Speed |
|---|---|---|---|---|---|---|---|---|
| Unit | mm | kg/㎠ | ㎠ | g | ㎤/s | m | r.p.m | |
| VTU-100HC | S | 28 | 3200 | 92 | 86 | 83 | 150 | 0-300 |
| A | 32 | 2800 | 120 | 112 | 108 | |||
| B | 36 | 2500 | 151 | 141 | 136 | |||
| VTU-150HC | S | 40 | 3000 | 251 | 221 | 118 | 200 | 0-250 |
| A | 45 | 2600 | 318 | 281 | 149 | |||
| B | 50 | 2310 | 392 | 346 | 185 | |||
| VTU-200HC | S | 45 | 2750 | 397 | 350 | 144 | 250 | 0-250 |
| A | 50 | 2310 | 490 | 433 | 177 | |||
| B | 55 | 1920 | 593 | 524 | 215 | |||
| VTU-250HC | S | 50 | 2430 | 490 | 433 | 181 | 250 | 0-200 |
| A | 55 | 1970 | 593 | 524 | 219 | |||
| B | 60 | 1570 | 706 | 624 | 260 | |||
| VTU-300HC | S | 55 | 2100 | 653 | 577 | 219 | 275 | 0-200 |
| A | 60 | 1700 | 777 | 686 | 260 | |||
| B | 65 | 1400 | 912 | 806 | 312 |
| Item | Clamping Force | Clamping Stroke | Mold Thickness (Min) | Maximum Daylight | Ejector Force | Ejector Stroke |
|---|---|---|---|---|---|---|
| Unit | ton | mm | mm | mm | ton | mm |
| VTU-100HC | 120 | 450 | 250 | 700 | 2.7 | 120 |
| VTU-150HC | 150 | 500 | 300 | 800 | 4.3 | 150 |
| VTU-200HC | 200 | 550 | 350 | 900 | 4.3 | 175 |
| VTU-250HC | 250 | 600 | 350 | 950 | 4.3 | 200 |
| VTU-300HC | 300 | 650 | 400 | 1050 | 7 | 200 |
| Item | Total wattage | Motor Capacity | Heater Capacity | Machine Dimension(L×W×H) | Oil Tank Capacity | Machine Weight |
|---|---|---|---|---|---|---|
| Unit | kw | kw | kw | m | ℓ | ton |
| VTU-100HC | 25.5 | 18 | 7.5 | 2.6x1.3x2.5 | 300 | 6 |
| VTU-150HC | 32 | 23 | 9 | 3.4x1.7x3.0 | 400 | 7.5 |
| VTU-200HC | 39 | 28 | 11 | 3.4x1.9x3.3 | 500 | 11 |
| VTU-250HC | 41 | 28 | 13 | 3.8x2.0x3.6 | 700 | 15 |
| VTU-300HC | 43 | 28 | 14 | 4.2x2.3x4.0 | 800 | 19 |
